The 3km Multi-band Fixed UAV Detection and Defense System is a professional low-altitude security monitoring equipment that utilizes advanced spectrum sensing and signal analysis technology to provide real-time monitoring and early warning of drone activities within a 3km radius. Through multi-band signal scanning and intelligent recognition algorithms, the system can accurately detect and identify mainstream drone models, providing all-weather, comprehensive airspace security protection for important areas.
Product parameters
Support Frequencies | 900M 2.4G,5.8G,other bands customizable |
Detection Range | 5KM |
Detection Sensitivity | ≥ -115dBm(25kHz) |
Direction Directivity | 360° Omnidirectional |
Direction Finding Accuracy | Moving ≤ 10°, Hovering ≤ 3° |
Adaptable communication modulation method | FM, 2FSK, 4FSK, GFSK, MSK, BPSK, QPSK, 16QAM, 64QAM, OFDM, DSSS, FHSS |
Dynamic Range | 70dB |
Frequency Detection accuracy | ≤1kHz(120MHz bandwidth) |
Simultaneous Detection | ≥30 Drone |
Tuning range | 70MHz~6GHz |
Voltage | AC 110V to 220V±20V |
Detection Method | Panoramic scan, channel scan |
Working Ability | Can work continuously 24 hours a day |
