Yh-C47 Ly120 The Load of 100 Kg of Multi-Purpose Drone

2

Flight control

A high-performance professional flight control system

3

Remote control

Yunzhuo G20 Integrated Digital Remote Control (7-inch screen, maximum control range 30 km) Dual Remote Controls

4

Power kit

Hobwing H13 coaxial power kit, carbon fiber propellers, 4 sets

5

Battery

One set of batteries, two 24S*67000mAh batteries, totaling approximately 12 kWh.

6

Charger

2 3kW 24s chargers

7

FPV Camera

 C12 gimbal (Configurable night vision gimbal

8

Thrower

Four 30kg throwers with a lifting set

2

Propeller material

carbon fiber

12

Battery life

57 minutes (no load, retain 15% battery)
32 minutes (50kg load, retain 15% battery)
20 minutes (100kg load, retain 15% battery)
18 minutes (120kg load, retain 15% battery)

3

Maximum takeoff weight

230kg

13

propeller material

carbon fiber

4

Layout wheelbase

2450mm

14

fuselage material

T700 (carbon fiber, 75 aluminum alloy)

5

unfolded size

1900*1950*720

15

power kit

Hobwing H13 24S

6

Folded body dimensions

1650*1100*720

16

operating voltage

24s  96V

7

bare device weight

58kg

17

battery material

Semi-solid mechanism, PVC casing

8

battery weight

42kg

18

battery capacity

One set of batteries, Two 24S*67000mAh, approximately 12 kWh.

9

Flight distance

0-20km

19

propeller size

1447mm (57 inches)

10

Flight altitude

0-4000m

20

Main features

One-click takeoff, one-click landing, and out-of-control return
Real-time view of aircraft flight status, images, video, voltage, coordinates, altitude, speed, distance, etc
