Yh-C46 Ly80 80 Kg Goods Transport Drone

2

Flight control

A high-performance professional flight control system

3

Remote control

Yunzhuo G20 Integrated Digital Remote Control (7-inch screen, maximum control range 30 km) Dual Remote Controls

4

Power kit

Hobwing X15 coaxial power kit, carbon fiber propellers, 4 sets

5

Battery

One set of batteries, two 18S*60000mAh batteries, totaling approximately 9 kWh.

6

Charger

2 3kW 12-18s chargers

7

FPV Camera

Fixed camera or C10pro gimbal

2

Maximum load

100kg

12

Battery life

47 minutes (no load, retain 15% battery)
25 minutes (50kg load, retain 15% battery)
18 minutes (80kg load, retain 15% battery)

3

Maximum takeoff weight

190kg

13

propeller material

carbon fiber

4

Layout wheelbase

2400mm

14

fuselage material

T700 (carbon fiber, 75 aluminum alloy)

5

unfolded size

1900*1900*1000

15

power kit

Hobwing X15 18S

6

Folded body dimensions;

1900*1900*1000

16

operating voltage

18s  66V-81V

7

bare device weight

62kg

17

battery material

Semi-solid mechanism, PVC casing

8

battery weight

30kg

18

battery capacity

One set of batteries, Two 18S*60000mAh, approximately 9 kWh.

9

Flight distance

0-12km

19

propeller size

1600mm (56 inches)

10

Flight altitude

0-4000m

20

Main features

One-click takeoff, one-click landing, and out-of-control return
Real-time view of aircraft flight status, images, video, voltage, coordinates, altitude, speed, distance, etc
