Product presentation
This product integrates reception of all GNSS frequency bands and employs a deeply-coupled integrated navigation algorithm to achieve high-precision positioning and anti-interference capabilities. Compliant with ASIL B functional safety level, it effectively handles harsh envir onments such as satellite signal interference, obstruction, and multipath effects, delivering continuous, real-time, trustworthy high precision po sitioning results and reliable anti-interference effectiveness.
Technical parameters
Specifications | parameter |
Support system | BDS, GPS, GLONASS, Galileo |
Single point positioning accuracy | ≤2m(1σ,PDP≤4)(Without interference) |
First positioning time | Cold start time: ≤40s |
Motion Compatibility | Velocity: ≤500 m/s; Acceleration: ≤4g. |
Timing accuracy | ≤20 ns(RMS) |
Capacity of resisting disturbance | 65dBc |
Power dissipation | ≤60mA@5V |
Joggle | 1 x UART 232 |
Size | (42±1)x(38±1)x(13±1)mm |
Weight | 32±1g |
